look @ the pics and let me know what goes where

-Zach

06-25-2003, 03:05 PM

boostdfd3s

Senior Member

Thread Starter

Join Date: Oct 2002

Location: St. Louis

Posts: 276

pic 2

Attached Thumbnails

Uim Electrical Connections-dsc00019__small_.jpg

06-25-2003, 03:13 PM

twinturborx7pete

Senior Member

Join Date: Dec 2001

Location: Panama City Beach, Florida

Posts: 993

A- Air Temp

C - Double Throttle.

06-25-2003, 03:16 PM

boostdfd3s

Senior Member

Thread Starter

Join Date: Oct 2002

Location: St. Louis

Posts: 276

i wasnt looking for what they do....i need to have them matched to those connectors. like 1-a 2-b 3-c or w/e

06-25-2003, 03:31 PM

ccarlisi

Senior Member

Join Date: Aug 2002

Posts: 502

To the best of my memory all the connectors are unique in shape. meaning you can't put the wrong one in the wrong place. Look closely at them. It's been more than a year since I've had my uim off so I might be wrong.

06-25-2003, 03:34 PM

2 HOTT

Senior Member

Join Date: Dec 2001

Posts: 140

Connectors are all keyed so that they will only fit on one sensor. From the pic it would look like a-1 b-2 and c-3.

06-25-2003, 11:57 PM

twinturborx7pete

Senior Member

Join Date: Dec 2001

Location: Panama City Beach, Florida

Posts: 993

Quote:

Originally Posted by boostdfd3s' date='Jun 25 2003, 12:16 PM

i wasnt looking for what they do....i need to have them matched to those connectors. like 1-a 2-b 3-c or w/e

type of question is that?

they only fit certain ones...

06-25-2003, 11:59 PM

boostdfd3s

Senior Member

Thread Starter

Join Date: Oct 2002

Location: St. Louis

Posts: 276

haha, sorry about that man....it was hot as hell today and i was gettin frustrated..its all good now tho, the intake is in and hooked up correctly. Now if i could just fix my jumpy 2k-2500rpm idle....
