Turbo 2 Powered Fb
11-28-2003, 12:35 AM
#1
Senior Member
Thread Starter
Join Date: Oct 2003
Location: San Antonio, TX
Posts: 194
hey gang, i need help. i'm wondering weither or not to put a turbo 2 engine in my fb. if you could, please tell me what i would have to go through inorder to get this project in the air. thanks in advanced.
(my sister, me, and my pride and joy..)
(my sister, me, and my pride and joy..)
11-28-2003, 07:25 AM
#2
Senior Member
Join Date: Dec 2002
Location: Perth, Western Australia
Posts: 1,788
First off, Welcome to nopistons
Secondly, this topic comes up consistantly as a lot of us are in various stages of this same project. It won't hurt to do a search, but more inportantly check out all the links pinned at the top of the 1st gen forum.
For starters...
You'll need a FB 13b GSL-SE oil pan and front engine cover for the t2 engine. This way the engine will fit right in. The front cover will need to be tapped for the turbo return line.
The T2 transmission is an inch too long for your centre console, so you'll have to source a shift housing and shift rod from a FB gearbox to make it fit.
You'll need your tailshaft custom made to make up for the length difference.
Thats for starters, digest that and have a pretty long think about how much time, money, and knowledge you have to attempt a turbo engine swap. Not trying to put you off in any sense, just pre-warning you to some of the associated heartache.
Theres also diff/suspensino upgrades, wiring, engine management system, etc,etc
Secondly, this topic comes up consistantly as a lot of us are in various stages of this same project. It won't hurt to do a search, but more inportantly check out all the links pinned at the top of the 1st gen forum.
For starters...
You'll need a FB 13b GSL-SE oil pan and front engine cover for the t2 engine. This way the engine will fit right in. The front cover will need to be tapped for the turbo return line.
The T2 transmission is an inch too long for your centre console, so you'll have to source a shift housing and shift rod from a FB gearbox to make it fit.
You'll need your tailshaft custom made to make up for the length difference.
Thats for starters, digest that and have a pretty long think about how much time, money, and knowledge you have to attempt a turbo engine swap. Not trying to put you off in any sense, just pre-warning you to some of the associated heartache.
Theres also diff/suspensino upgrades, wiring, engine management system, etc,etc
11-28-2003, 11:27 AM
#3
Senior Member
Join Date: Jul 2001
Location: Richmond, KY
Posts: 595
Drifter covered most of it. The easiest way that I found was to buy a complete Turbo car. That way you have just about everything that you need to do the conversion. You'll need the wiring harness and ecu out of the Turbo. You'll also need another fuel pump, one to handle fuel injection. Custom driveshaft and quite a bit of fabrication. The biggest thing is that it can get quite costly to do. If you can't do most of the work yourself or have a hook-up, the cost will add up fast.
It's definately not a quick job, but I think it's worth it. Turbo 1st gens are ALOT of fun.
It's definately not a quick job, but I think it's worth it. Turbo 1st gens are ALOT of fun.
11-30-2003, 12:39 AM
#5
Senior Member
Thread Starter
Join Date: Oct 2003
Location: San Antonio, TX
Posts: 194
these past few weeks (even before i posted this) i've been talkin to acouple of friends and they said that they'd be more then happy to help out with the turbo swap, and following this my friend justin said that he'd give/sell (i insisted that i'd buy) his extra turbo 2 harness off his 88 t2 motor and i'm getting a turbo 2 motor and trans for 500, but its a 87 or 86 t2 motor so i dont know if it'll work but. i checked the motor out and it seems pretty good, not only to me but close shop teacher of mine also. so all i need now is parts to buy and the fabrications to do. money is somewhat of an issue to me but in the end, it seems it'd be well worth the wait.
if anyone could be of even more great help that you guys have already done for me, please show me or even if thats too much help me find a link to show a t2 swap. thanks guys for your help and no offense takin drifter, the honest truth is better then a lie.
if anyone could be of even more great help that you guys have already done for me, please show me or even if thats too much help me find a link to show a t2 swap. thanks guys for your help and no offense takin drifter, the honest truth is better then a lie.
11-30-2003, 01:10 AM
#6
Senior Member
Join Date: Dec 2002
Location: Minnesota
Posts: 911
http://www.rx7club.com/showthread.php?s=&t...25&pagenumber=1 that should keep you busy for a few days.
11-30-2003, 01:16 AM
#7
Senior Member
Join Date: Dec 2002
Location: Minnesota
Posts: 911
11-30-2003, 07:54 PM
#8
Senior Member
Thread Starter
Join Date: Oct 2003
Location: San Antonio, TX
Posts: 194
thanks everyone for your help and i'm doin my research on this project still, and if anyone has anything that they ran into that gave them a major problem during this swap, could you please let me know so i know what to expect? thanks if you can and if you couldnt, its no problem, still much love to ya.
11-30-2003, 09:28 PM
#9
Senior Member
Thread Starter
Join Date: Oct 2003
Location: San Antonio, TX
Posts: 194
hey guys i was at this site and this guy put what you would need inorder for a t2 swap in a fb and he put in his list,"Rear Dif:
81-83 GSL. NOT SE. Limited Slip Dif. W/disc brakes, or if you dont
want to change the whole rear-end you can swap just the Dif. This
swap will retain the stock 4x110mm bolt patern.
If you choose the complete swap don't forget the E-brake cables."
i was told by a couple of guys that i have to modify my tailshaft. well what do i have to modify specificly? and is this true that i can use this rear-end, because i already have this rear-end.
81-83 GSL. NOT SE. Limited Slip Dif. W/disc brakes, or if you dont
want to change the whole rear-end you can swap just the Dif. This
swap will retain the stock 4x110mm bolt patern.
If you choose the complete swap don't forget the E-brake cables."
i was told by a couple of guys that i have to modify my tailshaft. well what do i have to modify specificly? and is this true that i can use this rear-end, because i already have this rear-end.
11-30-2003, 09:28 PM
#10
Junior Member
Join Date: Oct 2003
Posts: 25
ok if you already have the harness and the complete engine of the S4, you are now missing TII coils, the S4 TII Air flow meter, boost sensor (located near passenger side strut tower of a S4 TII), knock control unit (metal box on the passenger kick panel or a S4 TII) the atmospheric pressure sensor located near the knock sensor, that is if all this did not come with the harness.
On top of that you will need the other stuff previously stated above...
1st gen front cover,
Racingbeat 12a-13b engine mounb braket (or modify stock one)
high pressure fuel pump (for fuel injected cars)
and a custom exhaust.
Thats the basics you need to do the swap, after that, if you decide to change the transmission, a little more custom work is required.
On top of that you will need the other stuff previously stated above...
1st gen front cover,
Racingbeat 12a-13b engine mounb braket (or modify stock one)
high pressure fuel pump (for fuel injected cars)
and a custom exhaust.
Thats the basics you need to do the swap, after that, if you decide to change the transmission, a little more custom work is required.
